10 Series 1/4″ (-04) Insert with 1/4″ (-04) Standard Hose Barb – Carbon Steel
Pneumatic Quick Coupling
Equivalent to Parker 8C
TRU-Flate Design – Automotive Interchange
Manual Sleeve
Single Shut-Off
Insert Size: 1/4″
Carbon Steel Insert
For Hose with ID: 1/4″
Temperature Range: -4°C to +121°C
Rated Pressure: 300psi / 20Bar
Locking Device: 4 Balls
Features:
Integral sleeve guard resists accidental disconnection.
Tubular valve delivers high air flow with minimal pressure drop.
Brass body for added corrosion resistance.
Standard seal in Nitrile.
Steel nipples are case hardened
Applications:
Air compressors, Pneumatic tools, Water, Grease, Paint
The coupler half contains a shut-off valve that is automatically opened when a mating nipple is inserted and automatically closed when the nipple is removed.
Other know codes: Q-8C, 8C, CP21-42, GL-CP21-42
PLEASE NOTE THAT COURIER COST MAY NOT BE 100% ACCURATE ON HOSE ASSEMBLIES OR BULK, IT IS ADVISED TO REQUEST COURIER COST SEPERATE UPON ORDERING. YOU ARE WELCOME TO CALL OR EMAIL TO GET ACCURATE COSTING ON COURIER PRIOR TO ORDERING.
Items in stock may sometimes differ slightly from those in the pictures, but they are functionally the same.
